In-Stock Filter, BIG A Crosses
BIG A - 91024
Ready to Ship: 0
List Price: $25.80
Your Price: $20.64
Savings: $
5.16
View Tech Data
X
Technical Data For:
BIG A-91024
Filter Type:
Hydraulic
Media Type:
Cellulose
Fluid Type:
HH / HL / HM / HV
Height:
5.95
OD Top:
1.97
ID Top:
0.97
OD Bottom:
1.97
Collapse Pressure (PSI):
304
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Flow Direction:
Outside-In
Beta Ratio 1:
2/25
Micron 1:
25
Close
BIG A - 91095
Ready to Ship: 0
List Price: $189.64
Your Price: $151.71
Savings: $
37.93
View Tech Data
X
Technical Data For:
BIG A-91095
Close
BIG A - 91097
Ready to Ship: 7
List Price: $43.72
Your Price: $34.98
Savings: $
8.74
View Tech Data
X
Technical Data For:
BIG A-91097
Filter Type:
Hydraulic
Media Type:
Cellulose
Fluid Type:
HH / HL / HM / HV
Height:
7.48
OD Top:
4.17
ID Top:
2.84
OD Bottom:
4.17
ID Bottom:
0.41
Collapse Pressure (PSI):
145
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Flow Direction:
Inside-Out
Gasket Material:
Buna
Beta Ratio 1:
2/10
Micron 1:
10
Close
BIG A - 91100
Ready to Ship: 6
List Price: $22.60
Your Price: $18.08
Savings: $
4.52
View Tech Data
X
Technical Data For:
BIG A-91100
Filter Type:
Hydraulic
Media Type:
Cellulose
Fluid Type:
HH / HL / HM / HV
Height:
3.38
OD Top:
1.65
ID Top:
0.90
OD Bottom:
1.65
Collapse Pressure (PSI):
290
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Flow Direction:
Outside-In
Gasket Material:
Viton
Beta Ratio 1:
2/10
Micron 1:
10
Close
BIG A - 91109
Ready to Ship: 30
List Price: $155.84
Your Price: $124.67
Savings: $
31.17
View Tech Data
X
Technical Data For:
BIG A-91109
Filter Type:
Hydraulic
Media Type:
Glass
Fluid Type:
HH / HL / HM / HV
Height:
18.50
OD Top:
3.66
ID Top:
1.73
OD Bottom:
3.66
ID Bottom:
1.73
Collapse Pressure (PSI):
73
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Capacity (GR):
83.416567
Filter Area (SQ IN):
929
Flow Direction:
Inside-Out
Gasket Material:
Buna
Beta Ratio 1:
200/9.9
Beta Ratio 2:
1000/12.4
Micron 1:
10
Close
BIG A - 91111
Ready to Ship: 0
List Price: $178.18
Your Price: $142.54
Savings: $
35.64
View Tech Data
X
Technical Data For:
BIG A-91111
Close
BIG A - 91120
Ready to Ship: 311
List Price: $20.04
Your Price: $16.03
Savings: $
4.01
View Tech Data
X
Technical Data For:
BIG A-91120
Filter Type:
Hydraulic
Media Type:
Cellulose
Fluid Type:
HH / HL / HM / HV
Height:
4.45
OD Top:
1.77
ID Top:
1.00
OD Bottom:
1.77
Collapse Pressure (PSI):
305
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Capacity (GR):
6.29
Filter Area (SQ IN):
85
Flow Direction:
Outside-In
Gasket Material:
Viton
Beta Ratio 1:
2/25
Micron 1:
25
Close
BIG A - 91121
Ready to Ship: 518
List Price: $30.82
Your Price: $24.66
Savings: $
6.16
View Tech Data
X
Technical Data For:
BIG A-91121
Filter Type:
Hydraulic
Media Type:
Glass
Fluid Type:
HH / HL / HM / HV
Height:
4.45
OD Top:
1.77
ID Top:
1.00
OD Bottom:
1.77
Collapse Pressure (PSI):
305
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Flow Direction:
Outside-In
Gasket Material:
Viton
Beta Ratio 1:
200/5.4
Beta Ratio 2:
1000/7.7
Micron 1:
5
Close
BIG A - 91122
Ready to Ship: 866
List Price: $29.42
Your Price: $23.54
Savings: $
5.88
View Tech Data
X
Technical Data For:
BIG A-91122
Filter Type:
Hydraulic
Media Type:
Glass
Fluid Type:
HH / HL / HM / HV
Height:
4.45
OD Top:
1.77
ID Top:
1.00
OD Bottom:
1.77
Collapse Pressure (PSI):
305
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Flow Direction:
Outside-In
Gasket Material:
Viton
Beta Ratio 1:
200/9.9
Beta Ratio 2:
1000/12.4
Micron 1:
10
Close
BIG A - 91124
Ready to Ship: 147
List Price: $43.60
Your Price: $34.88
Savings: $
8.72
View Tech Data
X
Technical Data For:
BIG A-91124
Filter Type:
Hydraulic
Media Type:
Cellulose
Fluid Type:
HH / HL / HM / HV
Height:
9.29
OD Top:
3.66
ID Top:
1.73
OD Bottom:
3.66
ID Bottom:
1.73
Collapse Pressure (PSI):
73
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Flow Direction:
Inside-Out
Gasket Material:
Buna
Beta Ratio 1:
2/25
Micron 1:
25
Close
BIG A - 91125
Ready to Ship: 700
List Price: $49.58
Your Price: $39.66
Savings: $
9.92
View Tech Data
X
Technical Data For:
BIG A-91125
Filter Type:
Hydraulic
Media Type:
Cellulose
Fluid Type:
HH / HL / HM / HV
Height:
9.60
OD Top:
2.36
ID Top:
1.42
OD Bottom:
2.36
Collapse Pressure (PSI):
305
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Flow Direction:
Outside-In
Gasket Material:
Viton
Beta Ratio 1:
2/10
Micron 1:
25
Close
BIG A - 91407
Ready to Ship: 11
List Price: $59.78
Your Price: $47.82
Savings: $
11.96
View Tech Data
X
Technical Data For:
BIG A-91407
Filter Type:
Hydraulic
Media Type:
Glass
Fluid Type:
HH / HL / HM / HV
Height:
8.18
OD Top:
2.99
ID Top:
1.50
OD Bottom:
2.99
Collapse Pressure (PSI):
305
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Capacity (GR):
59.18055
Filter Area (SQ IN):
605
Flow Direction:
Outside-In
Gasket Material:
Viton
Beta Ratio 1:
200/5.4
Beta Ratio 2:
1000/7.7
Micron 1:
5
Close
BIG A - 91408
Ready to Ship: 36
List Price: $122.24
Your Price: $97.79
Savings: $
24.45
View Tech Data
X
Technical Data For:
BIG A-91408
Filter Type:
Hydraulic
Media Type:
Wire Mesh
Fluid Type:
HH / HL / HM / HV
Height:
6.97
OD Top:
5.00
OD Bottom:
5.00
Thread Size:
1 1/2
Thread:
UNF
ADBV:
NO
Collapse Pressure (PSI):
145
Burst Pressure (PSI):
261
Flow Rate (GPM):
40 GPM
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Filter Area (SQ IN):
298
Flow Direction:
Outside-In
Gasket Material:
Buna
Micron 1:
125
Close
BIG A - 91413
Ready to Ship: 19
List Price: $53.44
Your Price: $42.75
Savings: $
10.69
View Tech Data
X
Technical Data For:
BIG A-91413
Filter Type:
Hydraulic
Media Type:
Cellulose
Fluid Type:
HH / HL / HM / HV
Height:
18.50
OD Top:
3.66
ID Top:
1.73
OD Bottom:
3.66
ID Bottom:
1.73
Collapse Pressure (PSI):
73
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Filter Area (SQ IN):
1143
Flow Direction:
Inside-Out
Gasket Material:
Buna
Beta Ratio 1:
2/10
Micron 1:
10
Close
BIG A - 91415
Ready to Ship: 147
List Price: $45.78
Your Price: $36.62
Savings: $
9.16
View Tech Data
X
Technical Data For:
BIG A-91415
Filter Type:
Hydraulic
Media Type:
Cellulose
Fluid Type:
HH / HL / HM / HV
Height:
9.29
OD Top:
3.66
ID Top:
1.73
OD Bottom:
3.66
ID Bottom:
1.73
Collapse Pressure (PSI):
73
Operating Temp Min (F):
-13
Operating Temp Max (F):
248
Flow Direction:
Inside-Out
Gasket Material:
Buna
Beta Ratio 1:
2/10
Micron 1:
10
Close
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
All In-Stock filters are manufactured to exacting specifications in fit, form and function and are equal to or better than the OEM specifications. In-Stock Filter and Western Technical Filter are not affiliated with the original manufacture, where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of our filter with the OEM filter.
